Applications: Single-phase asynchronous motors (washing machine, fan, air conditioning motors), shaded-pole motors, DC motors, power tools, stepper motors, wiper motors, car heater motors, motorcycle starter motors, and more.
| Model Number | Max Torque (N.m) | Lower Limit Torque (N.m) | Max Speed (rpm) | Max Power 5min (W) | Continuous Power (W) |
|---|---|---|---|---|---|
| CNC100 | 10m | 0.4m | 35000 | 25 | 10 |
| CNC200 | 20m | 0.6m | 30000 | 40 | 20 |
| CNC500 | 50m | 1.6m | 30000 | 50 | 30 |
| CNC1K | 0.1 | 0.004 | 25000 | 80 | 45 |
| CNC10K | 1 | 0.04 | 20000 | 450 | 250 |
| CNC50K | 5 | 0.2 | 15000 | 1200 | 600 |
| CNC300K S/F | 30 | 0.8 | 4000 | 3000 | 2500 |
* Multiple measures can be taken to increase the operating power upon request.
* Specifications not listed can be customized.
* L type is a vertical dynamometer for lawn mowers.
