1. Product Principle

The generator converts the 220v 50HZ electrical power into ultrasonic mechanical vibration power to the ceramic transducer and the welding head (horn). The vibration reaches up to 28,000 to 40,000 times per second. This power is transmitted through the booster and welding horn to the thermal plastic laminates to generate sufficient frictional heat. This heat breaks the molecular structure of the plastic, allowing the two plastic materials to melt and join. The welded area is nearly as strong as the matrix material.

2. Product Advantages

• Modular integrated circuit, easy for fixing and repairing.
• Automatic ultrasonic frequency tracking and sweeping.
• Higher output power compared to other brands.
• Ergonomic design for easy use and operation.
• Built-in fully-automatic protection circuit.
• Safe application with stable and reliable operation.
• Fuse protection and cooling device for the ceramic transducer.
• Imported electronic parts and durable components.
• Advanced digital integrated circuit with lightweight design.
• Adjustable power and amplitude from 50% to 100%.
• Specialized plug and socket for optimal connection.

3. Features and Applications

Optimized to eliminate heat welding defects such as yellowing, edge burning, and blocking. It is suitable for welding various thermal plastics including: HDPE, PP, PE, ABS, PVC, PC, EVA, PMMA, PS, PBT, PETG, and more. It is also effective for fiber cotton, chemical fiber, and metal hardware riveting, cutting, sealing, spot welding, and embossing.

• High production efficiency and superior weld quality.
• Environmental protection and energy-saving advantages.
• Portable, fast, clean, and safe operation.
• Customizable working, delay, and holding times.

4. Main Configuration

• 1* pcs Oscillator (transducer, booster welding head)
• 1* pcs Aluminum alloy with a gun or hand grip type nylon plastic shell
• 1* pcs Generator (drive power supply)
